Share: KALMAR.HE31.75

Reachstacker for empty and semi-laden container handling.

Everything within empty and semi-laden container handling. With the Kalmar DRG100-140 you can handle all types of containers (standard ISO, reefers, tanks, specials and flat racks) and slinged loads up to 14 tonnes precisely and safely. It also offers the rotation necessary for efficient action in confined spaces. Plus you get the quality that makes your business prosper, both in the short and long term.



Fully equipped – safe and sound.

The Kalmar DRG100-140 is extremely stable – it’s the only reachstacker on the market with the high-capacity 5.4 m wheelbase. It has the best combined lift capacity in rows 1-2-3, a spreader with the biggest side shift and 4 extra lift hooks, front and reverse tilts, twistlock status indicators, dual rotation motors and brakes, and a complete LED lamp kit as a standard.

Options included, among others, a Reverse Aid Warning System with a detection range from 0,5 up to 9 m.


Up to 90% less CO2 emission with HVO100 fuel.

Kalmar Stage 3, 4 & 5 reachstackers, forklifts, terminal tractors and empty container handlers fitted with Volvo or Cummins engines are now certified to use HVO100. If you own a certified machine, you just need to discuss with your local Kalmar support team if your equipment needs a minor upgrade or it is ready to start using HVO straight away.

It’s quick and easy to get fitted and will start cutting your CO2 emissions by up to 90% as soon as you start using HVO100 fuel.

To find out more about HVO100 click here.



Optimise your fleet.

Kalmar Insight is a performance management tool that allows you to track your equipment while operating, making it easier for you to make decisions that will help improve your overall operations.

Technical information

Información técnica Kalmar DRG100-140
Capacidad de elevación (lbs)
22000 - 31000
Batalla (pulgadas)
213"
Opciones de cabina
EGO
Stacking (toplift)
max 8 high, 3 deep
Engine
Volvo 185 kW
Stage emission
EU3/Tier 3, EU4/Tier 4F, EU5
Transmission
Dana LTE-14400
Models
Toplift
